Configure HTTP content caching in Apache on Ubuntu 16.04

Learn how to improve your website's performance by setting up HTTP content caching in Apache. Apache is capable of several kinds of caching, including key/value and file caching. This tutorial will focus on basic HTTP content caching, which is the most commonly used form of caching with Apache.


    vServer (VPS) from IONOS

    Low-cost, powerful VPS hosting for running your custom applications, with a personal assistant and 24/7 support.

    100 % SSD storage
    Ready in 55 sec.
    SSL certificate

    Apache cache states

    Apache's HTTP caching system considers its content as being in one of three states:

    • Fresh: New content which can be served up without being checked.
    • Stale: Content which has expired according to the rules you set, and which needs to be checked for a fresh copy.
    • Non-Existent: Content which is missing.

    When Apache receives a request, it checks the Time To Live (TTL) timestamp. If the TTL has expired, Apache will re-check that content to see if an updated version is available.

    • If an updated version is available: Apache will fetch that content and store it until the new TTL expires.
    • If the existing version has not been updated: Apache will update the TTL on the file and continue to serve it until the TTL expires.

    Apache uses the mod_cache module to evaluate the TTL on content, and determine what to do when it receives a request. It uses the mod_cache_disk module to store the data on the disk.

    Apache cache placement

    Before configuring HTTP caching, you will need to decide whether to place the cache: either in front or behind the web server.

    CacheQuickHandler is the setting which determines where the cache will be placed.

    Cache in front of web server

    If CacheQuickHandler is set to On, the cache will be checked before consulting Apache.

    This is a very fast way to serve content, because requests do not have to wait for Apache to finish the request. However this is not secure. Because all of the website content is put in front of the web server, no authentication happens.

    This means that if you have content which requires users to log in or authenticate, that content will be available to anyone who requests it.

    When configuring Apache HTTP caching, please note that CacheQuickHandler is turned on by default. If this will cause a security issue for your site, you will need to be sure to turn it Off.

    Cache behind web server

    If CacheQuickHandler is set to Off, the request will go through Apache before being fetched from the cache.

    This method is not as fast as putting the cache in front of the web server, because requests have to be processed through Apache. However, it allows for authentication, and is therefore best for any content where the user has to log in or authenticate before accessing content.

    For this tutorial, we will be setting CacheQuickHandler to Off.

    Cloud backup from IONOS

    Make costly downtime a thing of the past and back up your business the easy way!


    Enable the Apache modules

    To set up HTTP caching, first install the apache2-utils package:

    sudo apt-get update
    sudo apt-get install apache2-utils

    Enable the necessary Apache modules:

    sudo a2enmod cache
    sudo a2enmod cache_disk
    sudo a2enmod expires
    sudo a2enmod headers

    Then restart Apache for the changes to take effect:

    sudo systemctl restart apache2

    Add the virtual host configurations

    The following configuration is given as an example. It is a good starting place for a basic HTTP cache placed behind the web server, where content is set to expire 5 minutes after the last time it was accessed.

    There are many configurations you can add and change. A full list is available on the Apache website.

    Apache caching is best configured on a domain-by-domain basis. Open the Apache configuration file for the domain with the command:

    sudo nano /etc/apache2/sites-available/

    If you have not configured any Apache virtual hosts, you will be editing the default configuration file:

    sudo nano /etc/apache2/sites-available/000-default.conf

    Scroll to the bottom of the file and add the following lines above the line which reads </VirtualHost>:

    CacheQuickHandler off
    CacheLock on
    CacheLockPath /tmp/mod_cache-lock
    CacheLockMaxAge 5
    CacheIgnoreHeaders Set-Cookie
    <Location />
        CacheEnable disk
        CacheHeader on
        CacheDefaultExpire 800
        CacheMaxExpire 64000
        CacheIgnoreNoLastMod On
        ExpiresActive on
        ExpiresDefault A300

    Save and exit the file. Then check for configuration errors with the command:

    sudo apachectl configtest

    If there are no errors present in the file, restart Apache for the changes to take effect:

    sudo systemctl restart apache2

    Test the HTTP cache

    To verify that the caching system is working, check the directory where the cache is being stored. For example, first list the contents of the cache directory:

    ls -la /var/cache/apache2/mod_cache_disk/

    If there is very little traffic to your server, and you have just set up the caching, you will probably only see a few items:

    user@localhost:/var/www/html# ls -la /var/cache/apache2/mod_cache_disk/
    total 20
    drwxr-xr-x 5 www-data www-data 4096 Feb  1 21:43 .
    drwxr-xr-x 3 root     root     4096 Jan  6 03:20 ..
    drwx------ 3 www-data www-data 4096 Feb  1 21:42 2
    drwx------ 3 www-data www-data 4096 Feb  1 21:42 T

    Browse around your website, then check the directory again:

    user@localhost:/var/www/html# ls -la /var/cache/apache2/mod_cache_disk/

    total 20 drwxr-xr-x 5 www-data www-data 4096 Feb 1 21:45 . drwxr-xr-x 3 root root 4096 Jan 6 03:20 .. drwx------ 3 www-data www-data 4096 Feb 1 21:42 2 drwx------ 3 www-data www-data 4096 Feb 1 21:43 b drwx------ 3 www-data www-data 4096 Feb 1 21:42 T

    In the example above, the directory b was created in response to viewing one of the website's pages. This directory contains the server's cache of the page.

    You can also check your site's caching using a tool such as the one available on the SEO Site Checkup website or Seomator.
