What is Software Defined Networking (SDN)?
Software Defined Networking describes a network architecture that enables a purely software-based management of the network. For this purpose, the control plane implemented as standard in the hardware components of the control logic is abstracted from the hardware – in this context, one also speaks of the intelligence of the hardware, which is nothing more than its specific operating software (firmware). Put simply, the SDN concept stands for the separation of infrastructure and its configuration.
The data plane, on the other hand, remains part of the individual network devices (i.e. all routers, switches, and firewalls integrated in the network). With SDN, however, its task is exclusively to forward packets, which is why it requires little computing power. Among other things, this has the advantage that the devices do not require any elaborately developed firmware and are generally much cheaper than other network concepts.
The task field of the abstracted control plane, which is responsible for the proper data traffic in the SDN architecture and therefore has to carry out all relevant analyses, is considerably more complex. However, detached from the hardware and implemented in centralized software, it is highly programmable in software defined networking and therefore much more flexible in terms of network administration than is the case with other architectures.
How does SDN function?
A specific communication interface between control plane and data plane is required for the SDN software operating on the control layer to send instructions for proper packet traffic to the embedded network components. The best known solution for this is OpenFlow. Managed by the Open Networking Foundation (ONF), the communication protocol is the first standardized interface between the control and data levels of a software-defined networking architecture. In many SDN networks, it replaces the individual interfaces of the network devices, which also reduces the dependency on the hardware manufacturers.
OpenFlow is by far the most common, but by no means the only protocol for managing software defined networks: With NETCONF (RFC 6241), BGP (Border Gateway Protocol), XMPP (Extensible Messaging and Presence Protocol), OVSDB (Open vSwitch Database Management Protocol) and MPLS-TP (MPLS Transport Profile) there are alternatives which do not replace the standard protocol one to one, but which can nevertheless play a decisive role in the implementation of software defined networks. Proprietary protocols from Cisco Systems and Nicira are also used in some architectures.
Once communication between hardware and software is established, the administrator can quickly and easily get a good overall view of the network via the control layer and the respective SDN software, and manage the network devices through the central, software based control. This allows data streams to be managed with much greater efficiency than in networks where the various components each have their own control logic – greatly simplifying virtualization and resource scalability. This is also facilitated by the fact that routing and topology information is no longer distributed in fragments across all routers, but instead converges at a central location.
What SDN models are available?
The ideas and approaches for implementing SDN structures vary depending on the provider or operator and communication standard used. However, it is not always possible to draw a sharp dividing line between the individual models, so it could be that a software defined network has elements from different approaches.
Symmetrical vs. Asymmetrical SDN
Although the software-based principle basically provides the best possible centralization of network device intelligence, there are SDN approaches where the control plane’s scope is distributed across multiple control units. With such an asymmetrical model, the individual systems typically have the minimal information required for immediate operation, so that they will continue to function even if the central control unit fails. However, compared to the traditional symmetrical model, this also creates unnecessary informational redundancies.
Symmetric SDN approach
Maximum centralization of intelligence
Avoidance of redundancies; relief of the individual components
Availability and stability of the network stand and fall with the central control unit
Asymmetric SDN approach
Distribution of intelligence
The individual function even in the event of control logic failure
Redundancies of information; management of the network is more complex
Host-based vs. Network-based SDN
Another way to characterize Software Defined Networking is to look at the position of the control logic. In highly virtualized environments, for example, it makes sense to have the control plane processes handled by the system on which the hypervisor, i.e. the virtual machine manager, is hosted. If the SDN software is run on this host system, you can be sure that the necessary capacities are available for the resulting data load. The alternative to this host-based approach is to distribute SDN processing to dedicated routers as is common in traditional networks and therefore handle it based in a network.
Flood-based (proactive) vs. floodless (reactive) SDN
A third software-defined network model focuses on the way information is passed between the control plane and data plane. On the one hand, there is the option for the control instance to forward new information and changes to all participating network nodes through broadcast or multicast. This so-called flood-based or proactive SDN concept is advantageous if the centralization of intelligence does not play a role, e.g. because a symmetrical approach is used.
However, the more nodes a network has, the higher the network load will be with such a message transmission concept, which results in limited scalability. In larger networks, the floodless or reactive SDN model is therefore a popular alternative: In this case, the control plane ensures the correct functioning of all components by means of a controlled, reactive information transfer in which only the affected devices are clamped. The relevant information is usually obtained from special lookup tables, where distributed hashtag and caching methods are used.
Easy to move; parcels are shipped the shortest way possible
The network load automatically increases with each new node
All devices receive information relevant only to them
Problems with delivery of the information automatically lead to delays
What distinguishes Software Defined Networking from the classic network concept?
In the previous sections, the basic differences between a network based on the SDN approach and a classic network have become clear. The crucial point here is undoubtedly the separation of hardware and software, which was unthinkable years ago. Only since 2013 have there been devices that can implement this elementary aspect of software defined networking. It is therefore hardly surprising that future oriented technology has not yet been an issue in many companies.
The following sections therefore summarize the main difference between SDN and traditional networking before concluding with the goals and benefits as well as the concrete applications scenarios of SDN.
The differences between SDN and traditional networking in a tabular overview
|Software Defined Networking (SDN)||Traditional Networking|
|Centralized supervisory authority||Device-specific control instances|
|Celar separation between hardware and control level||Control of the hardware is integrated in the hardware|
|Freely programmable control plane||Device-specific control plane|
|Standardized protocols (e.g. via OpenFlow)||Manufacturer-specific protocols|
|Software access to data layer possible||Access to the data layer must be made directly on the hardware|
|Flexible, easily scalable architecture||Static, difficult to adapt architecture|
What are SDN’s goals and benefits?
Parallel to the demands placed on the computer’s computing power, the demands placed on the performance of networks are also continuously increasing: While digital networks are becoming larger and more complex, the degree of virtualization and the desire for maximum flexibility and scalability are also increasing at the same time. Since conventional devices, which are equipped with their own intelligence and process a large part of the processes independently, have not been able to meet these requirements for some time, the software-defined networking concept has been developed. With specific hardware without its own control instance, these goals are to be achieved or requirements met. The advantages over traditional networks can be summarized as follows:
- No configuration of individual devices or operating systems required
- Low maintenance and administration costs for the entire network.
- Lower hardware and operating costs.
- Enables dynamic allocation and monitoring of resources in real time
- Low dependence on hardware manufacturers
Possible application scenarios for Software Defined Networking
Thanks to its numerous advantages over the classic network concept, SDN is interesting for a large number of applications. Among other things, the software-defined network model is suitable for the following purposes:
- Quality of Service (QoS): The central overview of all network nodes makes it easier for the administrator to track how often a single connection is used. The administrator can react in real time to the knowledge gained and regulate data traffic accordingly in order to be able to deliver the promised bandwidth to all participants at all times.
- Manufacturer-independent device management: The focus on a uniform protocol such as OpenFlow makes SDN an excellent solution when devices from different manufacturers are to be combined and managed in a network.
- Manufacturer-independent functional expansion of the network: The freedom of SDN technology is also a good solution for scenarios in which networks should be easily expandable with new functions at any time – and the independence of device manufacturers also plays into the cards of users.
- Application-driven packet routing: SDN creates the basis for third-party applications to intervene in packet routing, i.e. change and adjust routes in the network. The prerequisite for this is that the control unit has a suitable interface.
- Central definition and distribution of security policies: Security policies can be passed on to the individual network switches simply and efficiently through the central control unit.
Together with other software-defined services, virtualized network structures are required, among other things, for setting up a Software Defined Data Centers (SDDC).
Conclusion: Flexible network architectures thanks to software defined networking
It is no coincidence that the SDN approach has been adopted by various network providers in recent years: Software defined networking optimizes the basic approach of hardware virtualization by removing manufacturer-specific restrictions and considerably simplifying the administration of a network. By decoupling the logic from the underlying hardware and the associated ability to control the network via software, network operators are well prepared for future developments and challenges in the IT industry.
