Set up a Node.js app for a website with Apache on Ubuntu 16.04

Node.js is a JavaScript runtime environment which lets you easily build server-side applications. This tutorial will explain how to set up a Cloud Server running Ubuntu 16.04 so that Node.js scripts run as a service, and configure the Apache server to make the script accessible from the web.

Although Node.js scripts can be run from the command line using screen, running the scripts as a service using the process manager PM2 gives the scripts a more robust set of behaviors. When run as a service this way, the scripts will automatically restart if the server is rebooted or the script crashes.

PM2 is a process manager for Node.js, with a wide range of features you can use to control and manage your Node.js scripts. Visit the official PM2 website for more information on using PM2.

    Requirements

    • A Cloud Server running Linux (Ubuntu 16.04).
    • A working domain name which points to the server.
    • Apache web server installed and running.

    vServer (VPS) from IONOS

    Low-cost, powerful VPS hosting for running your custom applications, with a personal assistant and 24/7 support.

    100 % SSD storage
    Ready in 55 sec.
    SSL certificate

    Install Node.js

    Update your server's packages and install curl with the following commands:

    sudo apt-get update
    sudo apt-get install curl

    Download the Node.js PPA:

    curl -sL https://deb.nodesource.com/setup_6.x -o nodesource_setup.sh

    Run the nodesource_setup.sh command to add the PPA to your server's package cache:

    sudo bash nodesource_setup.sh
    Note

    This script will update the server automatically. There is no need to run apt-get update a second time.

    Install Node.js:

    sudo apt-get install nodejs

    This will automatically install npm as well.

    Finally, install the build-essential package for npm:

    sudo apt-get install build-essential

    Create a sample Node.js application

    For this example we will begin by creating a separate directory in your website's document root for housing Node.js applications:

    sudo mkdir /var/www/html/nodejs

    Create the file hello.js in this directory:

    sudo nano /var/www/html/nodejs/hello.js

    Put the following content into the file:

    #!/usr/bin/env nodejs
    var http = require('http');
    http.createServer(function (request, response) {
       response.writeHead(200, {'Content-Type': 'text/plain'});
       response.end('Hello World! Node.js is working correctly.\n');
    }).listen(8080);
    console.log('Server running at http://127.0.0.1:8080/');

    Save and exit the file.

    Make the file executable:

    sudo chmod 755 hello.js

    Install PM2

    Use npm to install PM2 with the command:

    sudo npm install -g pm2

    Start the hello.js example script with the command:

    sudo pm2 start hello.js

    As root add PM2 to the startup scripts, so that it will automatically restart if the server is rebooted:

    sudo pm2 startup systemd

    Cloud backup from IONOS

    Make costly downtime a thing of the past and back up your business the easy way!

    Simple
    Secure
    Integrated

    Configure Apache

    To access the Node.js script from the web, install the Apache modules proxy and proxy_http with the commands:

    sudo a2enmod proxy
    sudo a2enmod proxy_http

    Once the installation is complete, restart Apache for the changes to take effect:

    sudo service apache2 restart

    Next, you will need to add the Apache proxy configurations. These directives need to be inserted into the VirtualHost command block in the site's main Apache configuration file.

    By common convention, this Apache configuration file is usually /etc/apache2/sites-available/example.com.conf on Ubuntu.

    Note

    The location and filename of a site's Apache configuration file can vary.

    Edit this file with your editor of choice, for example with the command:

    sudo nano /etc/apache2/sites-available/example.com.conf

    Scroll through the file until you find the VirtualHost command block, which will look like:

    <VirtualHost *:80>
    ServerName example.com
        <Directory "/var/www/example.com/html">
        AllowOverride All
        </Directory>
    </VirtualHost>

    Add the following to VirtualHost command block:

    ProxyRequests Off
       ProxyPreserveHost On
       ProxyVia Full
       <Proxy *>
          Require all granted
       </Proxy>

       <Location /nodejs>
          ProxyPass http://127.0.0.1:8080
          ProxyPassReverse http://127.0.0.1:8080
       </Location>

    Be sure to put these lines outside any Directory command blocks. For example:

    <VirtualHost *:80>
    ServerName example.com

       ProxyRequests Off
       ProxyPreserveHost On
       ProxyVia Full
       <Proxy *>
          Require all granted
       </Proxy>

       <Location /nodejs>
          ProxyPass http://127.0.0.1:8080
          ProxyPassReverse http://127.0.0.1:8080
       </Location>

        <Directory "/var/www/example.com/html">
        AllowOverride All
        </Directory>
    </VirtualHost>

    Save and exit the file, then restart Apache for the changes to take effect:

    sudo services apache2 restart`

    After Apache restarts, you can test the application by viewing it in a browser. You should see the message, "Hello World! Node.js is working correctly."
